MAX30100 Pulse Oximeter and Heart Rate Sensor Module (SpO₂/BPM)

Overview: High-Precision Biometric Monitoring

The MAX30100 Pulse Oximeter and Heart Rate Sensor Module is a fully integrated biosensor solution designed specifically for wearable health applications. It combines two internal LEDs (Red and Infrared), a photodetector, and a low-noise analog signal processing unit to accurately detect heart rate and blood oxygen saturation (SpO₂).

For advanced projects in the Bangladeshi tech sector—such as smartwatches, fitness trackers, and remote patient monitoring—the MAX30100 offers trusted, clinical-grade accuracy. It uses a non-invasive optical method, shining light through the fingertip to measure the absorbance of pulsing blood. Its advanced features, including Ambient Light Cancellation (ALC) and high Signal-to-Noise Ratio (SNR), ensure stable and accurate readings even with movement.

Crucially, the module features ultra-low power operation (with negligible standby current), making it the optimal choice for battery-powered, long-duration wearable devices.

Key Technical Features: Precision and Efficiency

• Sensor Chip: MAX30100 Integrated Pulse Oximeter and Heart-Rate Sensor.

• Biometric Outputs: Measures Heart Rate (BPM) and Blood Oxygen Saturation (SpO₂).

• Optical Sensing: Uses Red (660nm) and Infrared (880nm) LEDs to measure oxygenated and deoxygenated hemoglobin.

• Communication: Fast and simple I2C Interface (SDA, SCL) for communication with microcontrollers.

• Power Efficiency: Ultra-low-power operation, with shutdown current as low as 0.7µA, greatly extending battery life.

• Advanced Features: Includes integrated Ambient Light Cancellation and a 14-bit ADC for high-performance measurements.

• Operating Voltage: Wide voltage input range, typically 1.8V to 5.5V (The chip itself operates at 1.8V/3.3V).

• Internal Features: Includes a 16-word FIFO buffer and an integrated Temperature Sensor for calibration.

Applications: Dependable Results for Advanced Projects

• Wearable Health Tech: Integrating heart rate and SpO₂ monitoring into fitness bands and smart clothing.

• Remote Patient Monitoring: Creating low-power devices for long-term health data collection.

• Fitness and Exercise Tracking: Providing real-time biometric feedback during workouts.

• Educational Bio-sensing: Teaching the principles of pulse oximetry and non-invasive medical sensing.

Projectile Electronics Quality & Trust:

We provide the reliable MAX30100 module known for its high SNR and advanced optical system, ensuring the most accurate, clean health data possible. This commitment to professional-grade biometric sensing provides the technical confidence our local community needs for high-value e-health and wearable projects.

Package Includes:

1 × MAX30100 Pulse Oximeter and Heart Rate Sensor Module
