The Right Angle Male Header - 90 Degree Double Row is a robust board-to-board and board-to-cable interconnect solution engineered for applications requiring horizontal mating and efficient use of printed circuit board space. Its right-angle geometry enables low-profile routing while maintaining dependable electrical and mechanical performance in embedded systems, industrial electronics, and prototyping environments.
Manufactured for through-hole installation, this double row male header delivers strong solder joint retention and long-term reliability in environments subject to vibration or repeated mating cycles. The dual-row pin layout supports higher connection density compared to single-row headers, making it suitable for compact designs that require multiple signal or power lines routed through a single connector interface.
This connector is commonly used in development boards, control modules, and communication interfaces where mechanical stability and consistent electrical contact are critical. The right-angle orientation allows mating connectors or cables to exit parallel to the circuit board surface, improving enclosure fit and internal cable management.
Key Technical Specifications Datasheet Snapshot
• Connector type: Male pin header
• Row configuration: Double row
• Orientation: Right angle 90 degree
• Mounting method: Through-hole
• Electrical interface: Board-to-board or board-to-cable connection
• Application suitability: Signal and power interconnection in electronic assemblies
